MW12 Series Lifting Electromagnet for High-Speed Wire Rod (Coil)

MW12 Series Lifting Electromagnet for High-Speed Wire Rods (Coils)

This series is designed for lifting wire rod coils. Featuring a lightweight design and a reasonable structure (with only two contact points with the coil), it can replace the original MW22-□-54 series. Its magnetic structure is adaptable to coils of different diameters. The selection of the electromagnet depends on the length of the coil. It can lift multiple coils along the length direction of the electromagnet or multiple coils along the width direction. Multiple units can be used together, with the ability to turn each unit on and off independently, facilitating loading and unloading operations.
