MW22 Series Lifting Electromagnet for Bloom and Beam Blank

Product Features

Suitable for lifting large steel ingots, large blooming billets, section steel, and similar materials. Capable of generating deep magnetic penetration within a small adsorption area, without the need to adjust the lifting force based on deformation or twisting of the material. Can lift steel materials even with a certain air gap present. For steel materials of varying heights, the electromagnet can still generate strong magnetic force to securely hold and safely lift them.

Equipped with a balanced double-layer beam design, this electromagnet enables stable handling of long steel materials that are prone to bending.

The water-cooled high-temperature electromagnet is specifically designed by our company for lifting ultra-high-temperature steel materials, offering excellent heat dissipation and long service life.

Select the control equipment and other auxiliary devices based on the total power consumption of the combined number of units in use.

If the dimensions of the billets or beams to be lifted do not match the specifications in the catalog, or if the number of pieces to be lifted per cycle differs from the catalog, our company can provide custom designs based on the user's actual operating conditions to meet specific requirements.
