Powder Iron Remover

Description

The CGB series rotary semi-automatic magnetic separator is primarily designed to remove ferromagnetic impurities from materials that tend to cake or agglomerate. The motor-driven rotating magnetic rods prevent material blockage, ensuring that the product comes into full contact with the magnetic surface during flow.

Installation Methods

• Free fall

• In-line connection with material conveying pipelines

• Standalone unit for bulk materials

Application Industries

Food industry, chemical industry, pharmaceutical industry, plastic industry, wood processing industry, recycling industry, packaging industry, as well as iron removal from quartz sand, potassium feldspar, mica, fine powder, fly ash, and other fine powder materials ranging from 10 to 500 mesh.

Suitable Materials

The strong magnetic field effectively removes ferromagnetic contaminants from flowing, dry, free-flowing powders, fine granules (particle diameter < 6 mm), and flaky materials.

Standard Connection Sizes (mm)

150, 200, 250, 300, 350, 400, 450, 500

Custom sizes are available upon request based on site requirements.

Iron Discharge Method

Manual cleaning
